How long will a 24V 100Ah lithium battery run a trolling motor?

Runtime depends on the trolling motor’s average current draw, boat weight, speed, wind and water conditions. As a simple theoretical guide: 20A average draw: approximately 5 hours 40A average draw: approximately 2.5 hours 60A average draw: approximately 1.7 hours Trolling motors usually consume much less power at lower speeds, so real-world runtime can vary considerably.

Fast, Free Shipping
30-Day Money-Back Guarantee
Hassle-Free Warranty
Lifetime Customer Support

Payment Method

WattCycle 24V 100Ah LiFePO₄ Deep Cycle Battery for Trolling Motors, Marine & Off-Grid Power

Q: What charger should I use for this 24V LiFePO₄ battery?

Use a dedicated 29.2V LiFePO₄ battery charger or a properly configured 24V-compatible MPPT or DC-DC charging system. With a 29.2V 15A charger, a full charge from empty generally takes approximately 7–8 hours. Charging time varies according to remaining capacity, temperature and charger output.

Q: Can WattCycle 24V 100Ah batteries be connected in series or parallel?

Yes. The battery supports expansion up to 4P2S , providing a maximum system capacity of 20.48kWh. For a 24V system, connect matching batteries in parallel. A series connection increases the system voltage and should only be used with compatible 48V equipment. Always use batteries of the same model, capacity, age and state of charge, together with correctly rated cables, fuses and system protection.

Q: How long does the battery last, and what protection and warranty are included?

The Grade A+ LiFePO₄ cells are rated for 6000+ cycles at 80% DOD and can provide up to 10 years of service under suitable operating conditions. The built-in 100A BMS protects against overcharge, over-discharge, over-current and short circuits. It also features IP65 protection and low-temperature charging cut-off. The battery includes a 5-year warranty , with extended coverage available after product registration under the applicable warranty terms. Certifications and compliance documentation: IEC · UN 38.3 · CE-EMC · CE-RoHS · CE-Battery · FCC-SDoC · PSE · METI

$599.99 AUD$799.99 AUD

Extra 5% OFF with code Code: SPRING5

Simpler 24V Upgrade: Replaces 2 × 12V 100Ah batteries connected in series—fewer cables, fewer connections and easier installation in one 19.96kg battery.
Reliable 2560W Output: The built-in 100A BMS delivers up to 2560W continuous power while protecting against overcharge, over-discharge, over-current and short circuits.
Grade A+ LiFePO₄ Cells: Delivers 6000+ cycles at 80% DOD and up to 10 years of dependable deep-cycle power.
Ready for Outdoor Use: IP65 protection and automatic low-temperature charging cut-off provide added reliability in marine, touring and remote applications.
Expandable 24V Capacity: Connect matching batteries in parallel to expand from 2.56kWh to 10.24kWh for longer trips and larger energy requirements.
Certified & Warranty Backed: IEC · UN 38.3 · CE-EMC · CE-RoHS · CE-Battery · FCC-SDoC · PSE · METI, backed by a 5-year warranty.

CHOOSE YOUR SETUP

1 Battery · 2.56kWh: 24V trolling motors, day fishing and light marine loads.
1–2 Batteries · 2.56–5.12kWh: Marine house power, longer fishing trips and overnight stays.
2–4 Batteries · 5.12–10.24kWh: Small solar cabins, farm sheds and remote off-grid essentials.

Designed for 24V deep-cycle systems. Not suitable for engine starting.

QUANTITY

Free local shipping for all orders, except some areas need extra shipping cost.

24V 100Ah Battery User Manual.PDF

Our batteries come with a 5-year warranty, which can be extended to 7 years total upon product registration. Accessories are covered by a 1-year warranty, and like-new (refurbished) batteries include a 1-year warranty.

For full terms, conditions, and claim details, please visit:

Warranty Policy

Fast, Free Shipping
30-Day Money-Back Guarantee
Hassle-Free Warranty
Lifetime Customer Support

Payment Method

WattCycle 24V 100Ah LiFePO₄ Deep Cycle Battery for Trolling Motors, Marine & Off-Grid Power

$599.99 AUD

$799.99 AUD

Feature
Tech Specs
Faqs
Reviews

Solar Power Year Round Without a Generator

This video explores a DIY solar power system designed to provide year-round energy without a generator. The creator details their system's components, including lithium iron phosphate batteries, a charge controller, and solar panels, and explains how they work together to provide reliable power. They also discuss the cost of the system and its potential applications for off-grid living.

24V 100Ah Lithium Battery Tech Specs

GENERAL

Dimensions	L482 * W170 * H241 mm
Weight	44.0lbs / 19.96kg
Waterproof Rating	IP65
Warranty	7 years
Housing Material	ABS (Flame Retardant Plastic)
Terminal	M8 bolts

24V 100Ah LiFePO4 Battery Feature

Cell	EV Grade A+ LiFePO4 Cells
Nominal Voltage	25.6V
Nominal/Usable Capability	100Ah
Energy	2560Wh
Cycle Life	5,000+ cycles @100% DOD, 6,000+ cycles @80% DOD, 15,000+ cycles @60% DOD
Max Depth of Discharge (DOD)	100%
Max. Expansion	4P2S
Internal Resistance	≤40mΩ

Battery BMS

BMS	100A
Max. Continuous Output Power	2560W
Max. Continuous Charge Current	100A
Max. Continuous Discharge Current	100A

24V 100Ah LiFePO₄ Battery FAQs

This 2.56kWh deep-cycle lithium battery is designed for 24V trolling motors, marine house-power systems and small off-grid solar setups. It can support fridges, fish finders, navigation equipment, lighting, water pumps and other compatible 24V loads. It is not designed for engine starting.

Yes. It is suitable for many 24V trolling motors rated between 30 and 70 lb of thrust, provided the motor’s maximum continuous current does not exceed the battery’s 100A discharge limit. Always check the motor manual, recommended fuse, cable size and voltage before purchasing.

Yes. One WattCycle 25.6V 100Ah battery provides 2.56kWh—the same nominal energy as two 12.8V 100Ah batteries connected in series. Using one 24V battery reduces cables and connection points while simplifying installation and maintenance.

One battery is the most common choice for a standard 24V trolling motor or light marine loads. Choose two batteries in parallel for longer fishing trips, heavier boats or overnight marine use. Small cabins, farm sheds and remote solar systems may require two to four batteries, depending on daily consumption and available solar charging.

1 battery: 2.56kWh
2 batteries in parallel: 5.12kWh
3 batteries in parallel: 7.68kWh
4 batteries in parallel: 10.24kWh

Runtime depends on the trolling motor’s average current draw, boat weight, speed, wind and water conditions. As a simple theoretical guide:

20A average draw: approximately 5 hours
40A average draw: approximately 2.5 hours
60A average draw: approximately 1.7 hours

Trolling motors usually consume much less power at lower speeds, so real-world runtime can vary considerably.

Use a dedicated 29.2V LiFePO₄ battery charger or a properly configured 24V-compatible MPPT or DC-DC charging system. With a 29.2V 15A charger, a full charge from empty generally takes approximately 7–8 hours. Charging time varies according to remaining capacity, temperature and charger output.

Yes. The battery supports expansion up to 4P2S, providing a maximum system capacity of 20.48kWh. For a 24V system, connect matching batteries in parallel. A series connection increases the system voltage and should only be used with compatible 48V equipment.

Always use batteries of the same model, capacity, age and state of charge, together with correctly rated cables, fuses and system protection.

The Grade A+ LiFePO₄ cells are rated for 6000+ cycles at 80% DOD and can provide up to 10 years of service under suitable operating conditions. The built-in 100A BMS protects against overcharge, over-discharge, over-current and short circuits. It also features IP65 protection and low-temperature charging cut-off.

The battery includes a 5-year warranty, with extended coverage available after product registration under the applicable warranty terms.

Certifications and compliance documentation: IEC · UN 38.3 · CE-EMC · CE-RoHS · CE-Battery · FCC-SDoC · PSE · METI
